HIPERMAX S, which has evolved damping force characteristics, durability, and aesthetics, offers the best "Driving Comfort" in the history of HKS suspension.

• We have developed a kit for FL5 that combines the popular HIPERMAX S series with a front pillow upper. It allows for camber adjustment. By increasing the tire size and camber angle, you can prevent understeer and enjoy a powerful exterior.
• New technologies such as Dual PVS, Wide Range Needle, and Advanced Bump Rubber provide the best driving performance ever.
• Combined with the direct handling provided by the pillow upper mount, please enjoy the high-dimensional ride quality that HKS has pursued and it is not only fun and comfortable.　We pursue driving performance that lives up to the name TYPE-R, which is flexible yet runs well.

Application

Engine	K20C
Model Year	22/09 -
Remarks

Specification

	FRONT	REAR
Damping force adjustment	30 steps	30 steps
Base valve	-	-
Height adjustable lower bracket	×	〇
Upper mount	Spherical bearing	Rubber
Inverted/Normal type	Inverted	Normal
Damper/Spring layout	Coilover	Separated
Spring rate change at factory	Possible	Possible
Damping force adjustment with wire	-	〇
Helper spring (Spring rate N/mm)	〇 (19.8)	〇 (7.6)

Ride Height

		Factory *2	Test data	Adjustable range High - Low *3	Drivable range High - Low *4
FRONT	Ride height *1	652	652	654 ～ 632	654 ～ 642
	Against stock	-23	-23	-21 ～ -43	-21 ～ -33
REAR	Ride height *1	650	650	675 ～　631	675 ～　631
	Against stock	-22	-22	3 ～ -41	3 ～ -41

*1. Height from road surface to fender arch.
*2. Height at factory is the data tested at HKS with the setting of Full Kit. (HKS' recommended setting.)
*3. Adjustable range (However, the lowest value may not be road legal.
Even within the adjustable range, car body, arm etc. may contact. In such case, it will be hard to drive.
Damper oil leakage or any other problems caused by low ride height setting from the factory setting will void the warranty of the product.)
*4. Drivable range that there is no contact of car body or arms etc. (However, change of tire/wheel size may cause a problem.)
Caution). Actual data depends on each vehicle.

Kit information
Spring of Full Kit

	F	R
Spring rate N/mm(kgf/mm)	98 ( 10.0 )	78 ( 8.0 )
Free height (mm)	150	170
Spring type	Straight	Straight
Recommended range to change spring rate N/mm(kgf/mm)	±20 ( 2 )	±10 ( 1 )

Specification of damper

	F	R
Damping force (Rebound/Damping)N*	1055 / 623	348 / 412
Default position of dial	15	15
Remaining damper stroke (Rebound/Damping)mm	53 / 46	78 / 58

*The value of the damping force is at piston speed of 0.1m/sec.

Setting data

	F				R
	Default	Test	Drivable limit High *	Drivable limit Low *	Default	Test	Drivable limit High *	Drivable limit Low *
Length of case (mm)	306	←	306	306	415	415	439	392
Spring Set length(mm)	199	←	197	209	-	-	-	-
Length to ride hight adjuster (mm)	56	←	58	46	45	45	66	29
Lever ratio	1.00				1.18(spg) , 0.94(dmp)

* Refer to the above explanation *3 of ride height information for drivable high and low limitations.

Test vehicle information

		F	R
Vehicle weight kg		890　(890)	541　(540)
Tire size (Air pressure) kPa		265 / 30 - 19 ( 200 )	265 / 30 - 19 ( 200 )
Wheel size		9.5 JJ × 19 inset 60	9.5 JJ × 19 inset 60
Alignment (Toe/Camber)	Test data	out 1 mm / -2°55'	in 1 mm / -1°55'
	Standard value	in 1 ± 2 mm / -0°18' ± 0°30'	in 2 ± 2 mm / -1°12' ± 0°45'

* Test data at HKS.

The latest mechanism of the "Dual preload valve system" and "Wide range needle" is employed in the product. In addition, the laser marking of the HKS logo is carried out on the upper. The spring insulator is provided as standard equipment, and there is no need to worry about abnormal sound. Confident 3-year long-term warranty

Dual PVS

The preload valve system is employed in the product. Eliminating the damping force in the high-speed range and suppressing unnecessary movement. It provides a comfortable ride without pushing up.

3-year High-durable specification

It achieves high durability and low friction through the evolution of the tribology.
We brushed up on the ride's comfort and handling.

Provided Error Canceller

Error messages caused by removing the factory electronically controlled suspension can be avoided using the canceller included in the kit. Enjoy the driving experience only possible with vehicle height adjustment.

Vehicle Fitment

This product is made to fit the following vehicles:

• 2022+ Honda Civic FL5

If you're unsure whether this will fit your vehicle, contact our team of experts via email at support@zerooffset.com.au and send through a few photos of the car for us to verify fitment.
