• With the body rigidity increased in the Gen2, the damping characteristics have been reviewed. While pursuing responsiveness, event at the limit gentle characteristics have been achieved.
• The rear spring rate has been increased compared to the previous model, and high roll rigidity and stability have been achieved for circuit driving with high-grip tires, a re-tuning has been performed so that you can step on the accelerator boldly even in high-speed corners.
• Assuming that the car will be driven to and from the circuit, we paid particular attention to suppressing high-rate thrust and vibration by adjusting the damping force to a softer setting.
• We tested the main course of Fuji Speedway with ADVAN A052 265/35-18. Excellent results were obtained with the front camber at -4°40', front and rear toe out at 1.9mm, and the damping force dial set to 7 steps for the front and 6 steps for the rear. ※Please use this as a reference when setting up.

Application

Engine	G16E-GTS
Model Year	24/04 -

Specification

	FRONT	REAR
Damping force adjustment	30 steps	30 steps
Base valve	-	-
Height adjustable lower bracket	〇	〇
Upper mount	Spherical bearing	Spherical bearing
Inverted/Normal type	Inverted	Normal
Damper/Spring layout	Coilover	Separated
Spring rate change at factory	Possible	Possible
Damping force adjustment with wire	-	-
Helper spring (Spring rate N/mm)	〇 (19.8)	〇 (19.8)

Rate Height

		Factory *2	Test data	Adjustable range High - Low *3	Drivable range High - Low *4
FRONT	Ride height *1	657	641	681 ～ 627	681 ～ 627
	Against stock	-24	-40	0 ～ -54	0 ～ -54
REAR	Ride height *1	656	642	677 ～　606	677 ～　606
	Against stock	-21	-35	0 ～ -71	0 ～ -71

*1. Height from road surface to fender arch.
*2. Height at factory is the data tested at HKS with the setting of Full Kit. (HKS' recommended setting.)
*3. Adjustable range (However, the lowest value may not be road legal.
Even within the adjustable range, car body, arm etc. may contact. In such case, it will be hard to drive.
Damper oil leakage or any other problems caused by low ride height setting from the factory setting will void the warranty of the product.)
*4. Drivable range that there is no contact of car body or arms etc. (However, change of tire/wheel size may cause a problem.)
Caution). Actual data depends on each vehicle.

Kit information
Spring of Full Kit

	F	R
Spring rate N/mm(kgf/mm)	118 (12.0)	177 ( 18.0 )
Free height (mm)	150	170
Spring type	Straight	Straight
Recommended range to change spring rate N/mm(kgf/mm)	±20 ( 2 )	±20 ( 2 )

Specification of damper

	F	R
Damping force (Rebound/Damping)N*	755 / 672	486 / 500
Default position of dial	15	15
Remaining damper stroke (Rebound/Damping)mm	44 / 43	38 / 59

*The value of the damping force is at piston speed of 0.1m/sec

Setting Data

	F				R
	Default	Test	Drivable limit High *	Drivable limit Low *	Default	Test	Drivable limit High *	Drivable limit Low *
Length of case (mm)	307	291	331	277	293	282	309	267
Spring Set length(mm)	200	←	200	200	-	-	-	-
Length to ride hight adjuster (mm)	30	14	54	0	60	50	75	25
Lever ratio	1.00				(1.42(spg) , 1.32(dmp)

*Refer to the above explanation *3 of ride height information for drivable high and low limitations.

Test vehicle information

F	R
Vehicle weight kg		775　(770)	511　(510)
Tire size (Air pressure) kPa		265 / 35 - 18 ( 210 )	265 / 35 - 18 ( 210 )
Wheel size		9.5 JJ × 18 inset 40	9.5 JJ × 18 inset 45
Alignment (Toe/Camber)	Test data	out 1.9 mm / -4°40'	out 1.9 mm / -2°15’
	Standard value	in 1.6 ± 2 mm / -1°24' ± 0°45'	in 2.3 ± 2 mm / -1°56' ± 0°45'

Test data at HKS.

Parts List

*It may be changed without prior notice.

Vehicle Fitment

This product is made to fit the following vehicles:

• 2024+ Toyota GR Yaris Facelift

If you're unsure whether this will fit your vehicle, contact our team of experts via email at support@zerooffset.com.au and send through a few photos of the car for us to verify fitment.
